Ducati Panigale V4 R
Source: mediahouse.ducati.com Technical data
| Start of production | 2019 | Cylinder | V4 90° |
|---|---|---|---|
| Valves | 4 | Cooling | Liquid |
| Strokes | 4 | Displacement [ccm] | 998 |
| Bore [mm] | 81 | Stroke [mm] | 48 |
| Compression ratio | 14:1 | Max. Power [kW/hp] | 162/220 |
| RPM max. power [min-1] | 15250 | Max. torque [Nm] | 112 |
| RPM max. torque [min-1] | 11500 | Fuelt treatment | Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies with aerodynamic valves. Variable length intake system |
| EURO-norm | 4 | Gears | 6 |
| Ratio gears | 1=38/14 2=36/17 3=33/19 4=32/21 5=30/22 6=30/24 | Front sprocket | 15 |
| Rear sprocket | 42 | Clutch | Hydraulically controlled slipper and self-servo dry multiplate clutch |
| Wheelbase [mm] | 1471 | Rake [°] | 24,5 |
| Front suspension | Fully adjustable 43 mm Öhlins NPX pressurized fork with TiN treatment | Front wheel travel [mm] | 120 |
| Front wheel | 3-spokes forged aluminum alloy 3.50 x 17 | Front tyre | Pirelli Diable Supercorsa SP 120/70 ZR17 |
| Rear suspension | Fully adjustable Öhlins TTX36 unit. Aluminium single-sided swingarm, Adjustable pivot position +/- 3 mm | Rear wheel travel [mm] | 130 |
| Rear wheel | 3-spokes forged aluminum alloy 6.00 x 17 | Rear tyre | Pirelli Diable Supercorsa SP 200/60 ZR17 |
| Front brake | 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers | Rear brake | 245 mm disc, 2-piston calliper |
| Weight [kg] | 172 | Seat height [mm] | 830 |
| Colours | R-Design, Red | Colours wheels | Black |
| Max. rpm | 16500 | Instruments | Color-TFT 5 |
| Electric Features | DPL, DQS, DRL, GPS, Lap Timer EVO, PIT Limiter, Riding Modes, Power Modes, Bosch Cornering ABS EVO, DTC EVO, DWC EVO, DSC, EBC EVO |
| Start of production | 2019 |
|---|---|
| Cylinder | V4 90° |
| Valves | 4 |
| Cooling | Liquid |
| Strokes | 4 |
| Displacement [ccm] | 998 |
| Bore [mm] | 81 |
| Stroke [mm] | 48 |
| Compression ratio | 14:1 |
| Max. Power [kW/hp] | 162/220 |
| RPM max. power [min-1] | 15250 |
| Max. torque [Nm] | 112 |
| RPM max. torque [min-1] | 11500 |
| Fuelt treatment | Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies with aerodynamic valves. Variable length intake system |
| EURO-norm | 4 |
| Gears | 6 |
| Ratio gears | 1=38/14 2=36/17 3=33/19 4=32/21 5=30/22 6=30/24 |
| Front sprocket | 15 |
| Rear sprocket | 42 |
| Clutch | Hydraulically controlled slipper and self-servo dry multiplate clutch |
| Wheelbase [mm] | 1471 |
| Rake [°] | 24,5 |
| Front suspension | Fully adjustable 43 mm Öhlins NPX pressurized fork with TiN treatment |
| Front wheel travel [mm] | 120 |
| Front wheel | 3-spokes forged aluminum alloy 3.50 x 17 |
| Front tyre | Pirelli Diable Supercorsa SP 120/70 ZR17 |
| Rear suspension | Fully adjustable Öhlins TTX36 unit. Aluminium single-sided swingarm, Adjustable pivot position +/- 3 mm |
| Rear wheel travel [mm] | 130 |
| Rear wheel | 3-spokes forged aluminum alloy 6.00 x 17 |
| Rear tyre | Pirelli Diable Supercorsa SP 200/60 ZR17 |
| Front brake | 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers |
| Rear brake | 245 mm disc, 2-piston calliper |
| Weight [kg] | 172 |
| Seat height [mm] | 830 |
| Colours | R-Design, Red |
| Colours wheels | Black |
| Max. rpm | 16500 |
| Instruments | Color-TFT 5 |
| Electric Features | DPL, DQS, DRL, GPS, Lap Timer EVO, PIT Limiter, Riding Modes, Power Modes, Bosch Cornering ABS EVO, DTC EVO, DWC EVO, DSC, EBC EVO |
